NTRIP-M Rover GNSS/RTK receiver
499,00 €
- Description
- Additional information
Description
NTRIP-M for high precision application
NTRIP-M is a high precision rover platform.
1408 channel multi frequency and multiband receiver.
High end performance with RTK (RMS)
Horizontal: 0.8cm + 1ppm
Vertical: 1.5cm + 1ppm
● Supports GPSL1C/A/L2P/L5+BDS B11/B2/B31/B1C/B2a+GLONASS G1/G2+Galileo E1/E5b/E5a+QZSSL1/L2/L5 + SBAS
● All-constellation multi-frequency RTK engine and advanced RTK technology
● Independent tracking of satellite frequencies and 60dB narrowband anti-jamming technology
● All-constellation multi-frequency RTK engine and advanced RTK technology
● Independent tracking of satellite frequencies and 60dB narrowband anti-jamming technology
On board we have also the well know ESP32S which fits perfect and can be easily programmed by themselves if needed.
All Pin´s are available so it is easy to control everything and to create an application or product.
There are two USB 3.0 ports on board for power supply in and GNSS data out
Additional information
| Weight | 19 g |
|---|---|
| Dimensions | 83 × 46 × 12 mm |
